Application
Direct fit TD04H-15G Factory Turbo #: 49189-01301, 49189-01310, 49189-01320.
- For 1998- Volvo S70 with N2P23FT Engine
- For 1998- Volvo XC70 with B5254T Engine
CHRA Size
- TD04HL-15G
- Heat Shield Deep: 13.5 mm
Wheels Spec
- Compressor Wheel: 15G (43.4 / 55.7 mm)
(The 6+6 blades are better for low-end torque)
- Turbine wheel: 45.6 / 52 mm (3 types offered: STD, STS, STS 55. Click here to learn more about STS technology.)
Bearing Type
- Journal Bearing with 360 performance thrust bearing kit
Situation
- Brand New
The Set Includes
- 1 x CHRA
- 1 x Banjo bolt w/ washer for turbo oil feed side (#315-01101-010)
- 1 x Oil return gasket (#413-02006-001)
- 2 x Banjo bolts w/ washer for turbo water coolant side (#414-01101-018*2 + #416-01003-007*4)
- 1 x Balance Report with Anti-Counterfeit Tag
Provider
- Kinugawa Turbo Systems
Warranty
- No
