Description
APPLICATION
- Fits Engine Capacity: 1.4~2.4 Petrol / 2.8~4.5L Diesel
- Note: The maximum power stated for each turbocharger has been calculated based strictly on the choke flow of the compressor map (total turbo capability), representing the potential flywheel power. This product's Performance results depend highly on your vehicle’s modifications and tuning/calibration.
WHEEL SPEC
- Compressor Wheel: 48.3 / 68.0 mm
(The 6+6 blade is better for low-end torque; the 11+0 blade is for top-end speed)
- Nozzle area: AR.57
- Inlet: 2.4" non-anti-surge
- Outlet: 2"
- Cover with an optionally adjustable blow-off valve (BOV) or recirculating valve (BCV)
(Click here to learn about the difference between BOV and BCV.↗)
- The suggestion of BOV/BCV spring is according to the wastegate actuator spring pressure range.
- 1 x Green spring: 5~15 Psi (default installation)
- 1 x Yellow spring: 15~23 Psi (included)
- 1 x Blue spring: 23~30 Psi (included)
TURBINE HOUSING
- Nozzle area: 8cm^2 / AR.57
- Inlet: T25
- Outlet: 5-bolt Nissan CA18DET / SR20DET type with an optional 3" V-band flange kit
- Note: The maximum power stated for each turbocharger has been calculated based strictly on the choke flow of the compressor map (total turbo capability), representing the potential flywheel power. This product's Performance results depend highly on your vehicle’s modifications and tuning/calibration.
WHEEL SPEC
- Compressor Wheel: 48.3 / 68.0 mm
(The 6+6 blade is better for low-end torque; the 11+0 blade is for top-end speed)
- Turbine wheel: 56.0 / 49.2 mm
(3 types available: STD, STS, STS55. Click here to learn more about STS technology.↗)
- Nozzle area: AR.57
- Inlet: 2.4" non-anti-surge
- Outlet: 2"
- Cover with an optionally adjustable blow-off valve (BOV) or recirculating valve (BCV)
(Click here to learn about the difference between BOV and BCV.↗)
- The suggestion of BOV/BCV spring is according to the wastegate actuator spring pressure range.
- 1 x Green spring: 5~15 Psi (default installation)
- 1 x Yellow spring: 15~23 Psi (included)
- 1 x Blue spring: 23~30 Psi (included)
TURBINE HOUSING
- Nozzle area: 8cm^2 / AR.57
- Inlet: T25
- Outlet: 5-bolt Nissan CA18DET / SR20DET type with an optional 3" V-band flange kit
- Wastegate: Internal gated
BEARING TYPE
- Journal Bearing with 360-degree thrust bearing kit
COOLING TYPE
- Oil and Water-Cooled
ACTUATOR PRESSURE
- 1.0 bar / 14.7 Psi is the default.
- Please add a note or contact us if you need to change to 0.3 bar, 0.5 bar, 0.8 bar, 1.2 bar, 1.5 bar, 1.7 bar, or 2.0 bar actuator.
KIT INCLUDES
- 1 x turbocharger
- 1 x adjustable BOV or BCV (optional)
- 3 x BOV/BCV Springs
- 1 x block plate for BOV/BCV port
- 1 x top mount actuator bracket
- 1 x oil and water line kit
- 1 x gasket set turbine housing in/out
- 1 x 3" V-band adapter kit (optional) (#317-01006-001)
- 1 x Balance report with anti-counterfeit tag↗
SITUATION
- Brand New
- Full balance from Schenk MBRS110 Germany
PROVIDER
- Kinugawa Turbo Systems
WARRANTY
- One Year
- For complete peace of mind, Kinugawa Turbo Systems offers a KINUGAWA TROUBLE-FREE WARRANTY for 1 year from the purchase date to the original purchaser. If, for any reason, your turbocharger/s fails or has an issue, you can return it to us for a free overhaul and recondition or replacement depending on availability or the turbo problem. You can be assured that KINUGAWA has covered you no matter the issue.
